DP系列油封螺杆真空泵

DP系列油封螺杆真空泵

功    率:4~100KW

气    量:132~4800m³/h

参 数:

参 数:500~4500KG

参 数:

立即咨询 免费电话

订购热线: 400 777 0802

油封螺杆真空泵特点:
低螺杆转速/Low Rotor Ratation Speed
●保证了DP系列真空泵是极静音的产品—产品更低噪音为69dB(A)—所以能够将真空泵安装在周围有操作人员的主设备旁边。保证了产品的高可靠性与长使用周期/Denair low pressure screw air compressor adopalt ensure DNA-P series vacuum pump is extremely quiet-Produc ts for the lowe st noise 69dB(A)-it can be installed next to the pump around the operator's main device,Ensuring high relibility and long life cycle of the product.ts.high efficient oil-air separation system.Ensuring that the products,of high reliability and long life cycle.oil content of the compressed air under 3 ppm.
通用马达/General Motor
●DP真空泵的耐用,高可靠性并配置了较高同服系数的电机的特点保证了产品的长寿命/DAN-P vacuum durable.high reliability and comfigured servo motor features high coe fficient of ensuring a long product life.
真空泵进气口直接安装的模块化调节阀/Vacuum Pump Air Inlet Dirctly Mounted Modular Valve
●使设备能够按照现实的实际需求调节产品表现/It enables the device to adjust according to the actual needs of the product preformance.
●减少了设备运行中的波动对系统的影响/Reduce the impact of fluctuations in the operation of the device on the system.
●通过减少产品的启/停次数,减少了产品的磨损并缩短了维护周期/By reducing the product starts/stops,re duced wear and shorten product maintenance cycle.
隔音外罩/Soundproof Enclosure
●将噪音水平降至最低69dB(A),优化了产品外观/The noise levels to a minimum 69dB(A),Optimize the product appearance.
高效油分离器/Efficient Oil Separator
●滤芯极易替换,减少返流并优化产品性能/Filter easily replaced,reducing reflux and optimize.product performance.
●以很少的维护次数保证产品寿命/With minimal maintenance times to ensure product life.
●允许产品在接近大气压的气压范围工作,避免安装额外的附件/Allow product near atmospheric pressure range,acoid installing additional accessories.
可设定式油自动调温器/Oil Can Be Set Thermostats
●避免了冷凝水、特别是在特定的环境中,污染油箱/Avoiding condensation of water,particularly in a specific environment,pollution tank.
●针对潮湿应用环境优化油的循环减少冷凝水对机头的影响,提供持续表现/For wet application on the compressor element of condensate,provide continuous performance.
型号

功率
Kw

抽气速率
m³/min

终极压力
mbar/Pa

电压防护等级

传动方式

润滑油量
L

启动方式

外形尺寸
L×W×H

重量
Kg

空气出口管径
Kg

DP-4/2 4 2.2 0.5/50 380V/IP54 皮带 10 ϒ−Δ 950×950×1100 500 DN50
 DP-11/7 11 7.1 0.5/50 380V/IP54 联轴器传动 25 1450×950×1200 1000 DN65
DP-15/9 15 9.0 0.5/50 380V/IP54 25 2300×1300×1600 1200 DN80
 DP-18/12 18.5 12.0 0.5/50 380V/IP54 50 2300×1300×1600 1500 DN80
DP-22/16 22 16.0 0.5/50 380V/IP54 50 2400×1400×1700 1700 DN100
DP-30/18 30 18.0 0.5/50 380V/IP54 50 2400×1400×1700 2000 DN100
DP-37/26 37 26.0 0.5/50 380V/IP54 80 2400×1400×1800 2500 DN100
DP-55/40 55 40.0 0.5/50 380V/IP54 100 2500×1800×2100 3500 DN150
DP-75/49 75 49.0 0.5/50 380V/IP54 120 2800×1800×2100 4000 DN150
DP-90/59 90 59.0 0.5/50 380V/IP54 140 2800×1800×2100 4200 DN200
DP-110/80 110 80.0 0.5/50 380V/IP54 160 3000×2000×2100 4500 DN200
油封螺杆真空泵性能曲线

油封螺杆真空泵性能曲线
说明:

  德耐尔对产品不断改进,保有设计变更权,如有更改,恕不另行通知

油封螺杆真空泵应用:
针对复杂应用场合的可靠真空/Reliable Vacuum For Complex Applications
●DP系列真空泵为针对印刷、电子、塑料、包装、木材加工、制瓶、制罐等类似行业复杂应用的最佳真空解决方案。
DP series vacuum pump is the best solution for vacuum printing, electronics, plastics, packaging, wood processing, bottles, cans and other similar industry complex application program.
